Master the Home Assistant Button Card in 2026: A Deep Dive into Dynamic States

Last updated on February 04, 2026

Let’s continue our deep dive into the awesome capabilities of the Home Assistant Button Card. In this updated guide for 2026, we’re going to build two cards that are staples for any serious Home Assistant dashboard: one for monitoring percentage-based sensors and another for displaying complex device states. If this is your first time working with this card, I highly recommend you read the initial setup guide, as it lays the foundation for everything we’ll do here.

The first card will dynamically change its icon and color based on a battery’s charge level—a technique that works for any sensor that reports a percentage, like a smart blind’s openness or a water tank level. The second card is a more advanced example of smart home automation: it will show a light’s status while simultaneously displaying the temperature from a completely different entity, all in a compact, custom design powered by CSS Grid.

Building a Dynamic Battery Card with Home Assistant Button Card

The goal here is at-a-glance sensor monitoring that’s both visual and intuitive. We want one look to tell us everything we need to know about a device’s battery. We’ll be using JavaScript templates directly in our YAML to make the icon color shift from green to red as the level drops, and to have the icon itself reflect the remaining charge.

Here’s the code you’ll need. Just remember to replace sensor.t671h_battery_level with your own sensor’s entity ID.

type: custom:button-card
entity: sensor.t671h_battery_level
name: Phone Battery
show_state: true
styles:
  card:
    - border-radius: 15px
    - border: 2px solid var(--primary-text-color)
    - background-color: var(--ha-card-background, var(--card-background-color, #1c1c1c))
  name:
    - color: var(--primary-text-color)
    - font-weight: bold
  state:
    - font-weight: bold
    - color: var(--secondary-text-color)
  grid:
    - grid-template-areas: '"n" "i" "s"'
  icon:
    - color: |
        [[[
          const state = entity.state;
          if (state < 10) return "var(--error-color)";
          if (state < 20) return "var(--warning-color)";
          if (state < 40) return "yellow";
          return "var(--success-color)";
        ]]]
icon: |
  [[[
    const state = Math.round(entity.state / 10) * 10;
    if (entity.state > 95) return "mdi:battery";
    if (state == 0) return "mdi:battery-outline";
    if (isNaN(state)) return "mdi:battery-unknown";
    return "mdi:battery-" + state;
  ]]]

Code Breakdown:

• styles: For this 2026 version, I’ve replaced hard-coded colors (like rgb(255,255,255)) with Home Assistant theme variables (e.g., var(--primary-text-color)). This makes your card automatically adapt to your light and dark themes—a must-have for modern dashboards.
• grid: We’re using grid-template-areas to define a simple three-row layout: name (n), icon (i), and state (s).
• icon color: The JavaScript logic evaluates the entity’s state (entity.state). Based on the value, it returns a different color. I’ve simplified the logic and used system color variables for seamless integration.
• icon: Similarly, another JavaScript template selects the most appropriate icon from Material Design Icons. I’ve optimized this code to be more compact and efficient than the long chain of if statements you might see in older examples.

Advanced State Display: Combining a Light and Temperature Sensor

Now, let’s take it a step further and create some truly custom UI elements. This card not only shows if a light is on or off but also cleverly uses a corner space to display a temperature reading, creating a multifunctional information widget.

The key here is a more complex use of the CSS grid to position each element with precision. Be sure to swap light.sofa and sensor.living_room_temperature with your own entities.

type: custom:button-card
entity: light.sofa
name: Sofa
icon: mdi:sofa
show_state: false
styles:
  card:
    - border-radius: 20px
  grid:
    - grid-template-areas: '"i temp" "n temp"'
    - grid-template-columns: 1fr auto
    - grid-template-rows: 1fr auto
  icon:
    - color: |
        [[[
          return entity.state === 'on' ? 'var(--paper-item-icon-active-color)' : 'var(--paper-item-icon-color)';
        ]]]
custom_fields:
  temp: |
    [[[
      const temp_entity = states['sensor.living_room_temperature'];
      if (temp_entity) {
        return `<ha-icon
          icon="mdi:thermometer"
          style="width: 18px; height: 18px; color: var(--secondary-text-color);">
          </ha-icon>
          <span style="color: var(--primary-text-color); font-size: 14px;">
            ${Math.round(temp_entity.state)}°C
          </span>`
      }
      return '';
    ]]]

Code Breakdown:

• grid: The grid-template-areas: '"i temp" "n temp"' configuration creates a 2×2 grid. The icon (i) and name (n) occupy the first column, while our custom temperature field (temp) spans both rows of the second column.
• icon color: A simple JavaScript ternary operator assigns the active color if the light is on and the default color if it’s off. Clean and efficient.
• custom_fields: This is where the magic happens.
  • We define a field named temp.
  • Inside, the JavaScript accesses the state of a completely different entity (states['sensor.living_room_temperature']).
  • It then builds an HTML snippet that includes an icon and the rounded value from the sensor. This is an incredibly powerful technique for combining information in your Lovelace UI.

Common Issues & FAQ

Even with the perfect config, sometimes things don’t go as planned. Here are the solutions to the most common problems.
