KY-037 with ESPHome: Sound Detection, Not Fake dB

Albert BarnosellEditor and publisher of Tecnoyfoto

Updated August 6, 2026 · Code and limitations checked against current ESPHome documentation.

A KY-037 with ESPHome is useful for detecting a clap, knock, alarm or sudden rise in noise and sending that event to Home Assistant. Its digital output reports whether an adjustable threshold has been crossed, while its analog output can compare relative levels. The crucial limitation is simple: the KY-037 is not a sound level meter and does not measure calibrated decibels.

What the KY-037 is and what each pin provides

The module combines an electret microphone, an LM393 comparator, a potentiometer and two LEDs. The microphone responds to acoustic-pressure variations, but the board is not a calibrated measurement chain. Orientation, distance, supply voltage, microphone tolerances and clone circuitry all change the result.

Why an ADC formula cannot produce real dB

An ADC count only represents voltage. Converting it into sound-pressure level requires, at minimum, known microphone sensitivity, analog gain, frequency response, RMS processing, an acoustic reference, weighting such as dBA and calibration against a trustworthy source or meter. The old expression sensitivity × log10(ADC) + constant had none of that information: it produced a decibel-looking number, not a measurement.

Home Assistant provides sound_pressure for sensors that genuinely report dB or dBA. signal_strength is for signal power such as RSSI and is not appropriate either. This guide publishes the relative value as a percentage with state_class: measurement and no device_class.

That does not make the module useless. A relative reading is often enough to tell whether an alarm has started, a door was knocked or a machine has become louder than its baseline.

Parts required

• KY-037 and Dupont wires.
• NodeMCU ESP8266 or Wemos D1 mini. An ESP32 also works with the changes below.
• ESPHome Device Builder and the Home Assistant integration.
• A multimeter is recommended to check maximum AO/DO voltage if the module is powered at 5 V.

For a secure starting configuration, see our ESPHome WiFi guide. Related tested projects include the HC-SR04 with ESP8266 and DS18B20 with ESP8266.

KY-037 wiring for an ESP8266

Never connect a 5 V output directly to an ESP8266 GPIO or ADC. If your KY-037 version needs a 5 V supply, measure AO and DO and use a suitable resistor divider or level shifter.

Recommended option: digital threshold detector

For claps, knocks or a siren, DO is the simplest option. Turn the potentiometer until the trigger LED changes at the target sound. This block makes Home Assistant turn ON immediately and holds the event for 250 ms so a short pulse remains visible.

binary_sensor:
  - platform: gpio
    id: ky037_sound_trigger
    name: "KY-037 loud sound detected"
    icon: "mdi:volume-high"
    pin:
      number: D1        # GPIO5 on NodeMCU / D1 mini
      inverted: true    # Remove if your module behaves the other way
    filters:
      - delayed_off: 250ms

The potentiometer adjusts the physical comparator used by DO. A Home Assistant slider cannot move it or alter that threshold. The old “Sensitivity SoundEsp” control merely changed the fake-dB formula.

Analog option: relative sound level as a percentage

AO can compare sound activity from the same physical setup. Because every board differs, first watch the logs and replace 250 with your normal quiet reading and 750 with a repeatable high reading. The result is a relative 0–100% index, not dB.

substitutions:
  ky037_quiet_raw: "250"   # Replace with your observed quiet value
  ky037_loud_raw: "750"    # Replace with a repeatable high level

sensor:
  - platform: adc
    pin: A0
    id: ky037_adc_raw
    internal: true
    raw: true
    update_interval: 100ms
    samples: 32
    sampling_mode: max

  - platform: copy
    source_id: ky037_adc_raw
    name: "KY-037 relative sound level"
    icon: "mdi:waveform"
    unit_of_measurement: "%"
    device_class: ""
    accuracy_decimals: 0
    state_class: measurement
    filters:
      - calibrate_linear:
          method: exact
          datapoints:
            - ${ky037_quiet_raw} -> 0
            - ${ky037_loud_raw} -> 100
      - clamp:
          min_value: 0
          max_value: 100
      - exponential_moving_average:
          alpha: 0.2
          send_every: 1
      - throttle: 1s

sampling_mode: max retains the maximum from each group of readings, which helps catch transients. Smoothing reduces jumps and throttle protects the Home Assistant database from excessive updates. If your values decrease as sound rises, swap the two calibration points.

Complete current ESPHome configuration

This example combines secret-based WiFi, encrypted API, current OTA syntax, DO and AO. Use a 32-byte Base64 API key generated by ESPHome and keep every sensitive value in secrets.yaml.

substitutions:
  device_name: "ky037-sound-detector"
  friendly_name: "KY-037 Sound Detector"
  ky037_quiet_raw: "250"
  ky037_loud_raw: "750"

esphome:
  name: ${device_name}
  friendly_name: ${friendly_name}

esp8266:
  board: d1_mini

logger:

api:
  encryption:
    key: !secret api_encryption_key

ota:
  - platform: esphome
    password: !secret ota_password

wifi:
  ssid: !secret wifi_ssid
  password: !secret wifi_password
  ap:
    ssid: "KY037 Fallback"
    password: !secret fallback_password

captive_portal:

binary_sensor:
  - platform: gpio
    id: ky037_sound_trigger
    name: "Loud sound detected"
    icon: "mdi:volume-high"
    pin:
      number: D1
      inverted: true
    filters:
      - delayed_off: 250ms

sensor:
  - platform: adc
    pin: A0
    id: ky037_adc_raw
    internal: true
    raw: true
    update_interval: 100ms
    samples: 32
    sampling_mode: max

  - platform: copy
    source_id: ky037_adc_raw
    name: "Relative sound level"
    icon: "mdi:waveform"
    unit_of_measurement: "%"
    device_class: ""
    accuracy_decimals: 0
    state_class: measurement
    filters:
      - calibrate_linear:
          method: exact
          datapoints:
            - ${ky037_quiet_raw} -> 0
            - ${ky037_loud_raw} -> 100
      - clamp:
          min_value: 0
          max_value: 100
      - exponential_moving_average:
          alpha: 0.2
          send_every: 1
      - throttle: 1s

Example secrets.yaml:

wifi_ssid: "YOUR_NETWORK_NAME"
wifi_password: "YOUR_LONG_WIFI_PASSWORD"
api_encryption_key: "BASE64_KEY_GENERATED_BY_ESPHOME"
ota_password: "A_DIFFERENT_UNIQUE_PASSWORD"
fallback_password: "A_SECURE_FALLBACK_PASSWORD"

For larger files, see ESPHome substitutions and packages. Our Home Assistant secrets guide explains why credentials should not be embedded in public YAML.

ESP32 adaptation

On a classic ESP32, AO can use an ADC1 input-only pin such as GPIO34 with automatic attenuation. Pins vary by chip variant, so verify your board. Power or level-shift the KY-037 so neither output can exceed 3.3 V.

sensor:
  - platform: adc
    pin: GPIO34          # Classic ESP32; check other variants
    id: ky037_voltage
    attenuation: auto
    update_interval: 100ms
    samples: 32
    sampling_mode: max
    name: "KY-037 analog level"
    unit_of_measurement: "V"
    accuracy_decimals: 3
    state_class: measurement

Observe the voltage in quiet conditions and at your reference sound, then apply calibrate_linear if you want a relative percentage. Do not copy somebody else’s calibration points; they are not transferable between modules.

How to adjust the threshold

1. Power the final assembly in its intended location.
2. In quiet conditions, slowly turn the potentiometer until the DO LED changes state.
3. Move slightly away from that point to prevent continuous triggering.
4. Play the target sound at a realistic distance and readjust.
5. Repeat the test in Home Assistant instead of relying only on the LED.

Home Assistant automation example

An automation should react to a defined event, not treat the percentage as a sound meter. This example notifies when DO detects a loud sound and uses single mode to avoid overlapping runs:

alias: KY-037 loud sound alert
triggers:
  - trigger: state
    entity_id: binary_sensor.loud_sound_detected
    to: "on"
actions:
  - action: notify.mobile_app_your_phone
    data:
      title: "KY-037 detector"
      message: "Sound above the configured threshold was detected."
mode: single

Troubleshooting

When to choose another microphone

Choose an I2S microphone such as an INMP441/SPH0645 or a specified sound-level board if you need audio analysis, frequency information, RMS or a calibrated estimate. Legal or occupational limits require a certified sound level meter and the applicable procedure; a KY-037 cannot replace one.

Sources and checked documentation

• ESPHome ADC sensor and ESP8266 limits.
• ESPHome GPIO Binary Sensor.
• ESPHome sensor filters, calibration and base properties.
• Home Assistant sensor device classes.

Frequently asked questions

With the right expectations, the KY-037 is a cheap and useful event detector. The meaningful improvement is not inventing decibels; it is choosing DO or AO for the task, protecting the ESP inputs and calibrating a relative percentage against your own physical setup.
